151-02509 MP3M3

Multiple Cable Tie Mounting Plates, 108mmx12.7mm(LxW), M3 Screw, PA66W, -40 °C to +85 °C, Black
Manufacturer: HellermannTyton
SKU: 151-02509
MPN: MP3M3-PA66W-BK
Product Family: Screw Cable Tie Mount
Category: Cable Tie Mount
Unit Price: $0.7021
Availability: Out of stock - on backorder and will be dispatched once in stock (2 weeks).
Price list
Quantity Net Price /Piece
600 + $0.7021
750 + $0.6826
1000 + $0.6575
1250 + $0.6381
1750 + $0.6087
2500 + $0.5776
3000 + $0.5617
This product has a minimum quantity of 600
Total Price: $0.7021
Request a free, non-obligation quote today
Create your individual quote quickly and easily
Full Description

Many applications require each cable run to be firmly held in place but to be held separately from adjacent cable runs (example - control cabinets, machinery and military systems). The MP series of mounts can achieve this.

Features

  • Allow multiple cables to run in parallel
  • Simple to fix with two screws
  • Cables are fixed by using a cable tie through any combination of the available slots
Products specifications
Attribute name Attribute value
Country of Origin CN
Product Family Screw Cable Tie Mount
Global Part Number MP3M3-PA66W-BK
Product Base Type MP3M3
Material Abbreviation PA66W
Color Black
Lead Time 5 Weeks
Cable Tie Length (Metric) 108 mm
Cable Tie Length (Imperial) 4.3 inch
Width (Metric) 12.7 mm
Width (Imperial) 0.50 inch
Mounting Type Screw Mount
Mounting Screw Type M3 Screw
Material Polyamide 6.6, UV-resistant (PA66W)
Flammability UL 94-V2
UV Resistance Yes
EN 45545-2 Classification R22 HL2, R23 HL2
Operating Temperature -40 °C to +85 °C, (+105 °C, 500 h)
Specifications EN 45545-2
ELV compliant Yes
ROHS compliant Yes
Manufacturer HellermannTyton
Product Unit Piece
Drawing

HellermannTyton 151-02509 MP3M3-PA66W-BK Drawing PDFCAD_141597.pdfDrawing

Datasheet

HellermannTyton 151-02509 MP3M3-PA66W-BK Datasheet PDFTDS_151-02509_com.pdfDatasheet
