156-00969 T50RTC40FT6.35

Cable Tie With Fir Tree Mount, 202mmx4.6mm(LxW), For 6.25-6.75mm, 6.1-6.6mm(hexagonal) Hole, Bar Length 20.0 mm, Bundle Max. Φ45 mm, 225N Tensile Strength, PA66HS/PA66HIRHS, -40 °C to +105 °C, Black
Manufacturer: HellermannTyton
SKU: 156-00969
MPN: T50RTC40FT6.35-PA66HS/PA66HIRHS-BK
Product Family: Fir Tree Cable Tie For Round Hole
Unit Price: $0.2555
Availability: Out of Stock - on backorder and will be dispatched once in stock.
Price list
Quantity Net Price /Piece
800 + $0.2555
1250 + $0.2456
1750 + $0.2381
2500 + $0.2302
3500 + $0.2227
5000 + $0.2148
8000 + $0.2044
This product has a minimum quantity of 800
Total Price: $0.2555
Request a free, non-obligation quote today
Create your individual quote quickly and easily
Full Description

Primarily designed for fixing cable harnesses in the automotive industry their simplicity, and ease of use, has seen these parts used in everything from aircraft, to switch-gear, to washing machines.

Features

  • Pre-assembled 2-piece fixing tie with fir tree foot part
  • Cable tie head can be moved after bundling
  • Easy to assemble without the need for a tool
  • Disc adjusts tie for pressure from various directions and minimises access of dust and dirt
  • Fir tree foot part can be used for a variety of panel thicknesses
  • Suitable for use within threaded holes
Products specifications
Attribute name Attribute value
Country of Origin SG
Product Family Fir Tree Cable Tie For Round Hole
Global Part Number T50RTC40FT6.35-PA66HS/PA66HIRHS-BK
Product Base Type T50RTC40FT6.35
Material Abbreviation PA66HS/PA66HIRHS
Color Black
Lead Time 16 Weeks
Cable Tie Style 2-Piece Fixing Tie
Tie Closure Plastic Pawl
Variant Inside Serrated
Cable Tie Length (Metric) 202 mm
Cable Tie Length (Imperial) 8.0 inch
Cable Tie Width (Metric) 4.6 mm
Cable Tie Width (Imperial) 0.18 inch
Tie Strap Thickness 1.2 mm
Max. Bundle Diameter Φ45 mm
Min. Tensile Strength (Metric) 225N
Min. Tensile Strength (Imperial) 50 Lbs (22.9 Kgf)
Bundling Bar Length 20.0 mm
Mounting Type Fir Tree Mount
Fixing Hole Shape Circular Hole
Fitting Hole Diameter 6.25-6.75mm, 6.1-6.6mm(hexagonal)
Fitting Panel Thickness 0.7-4.0 mm
Material Polyamide 6.6, heat stabilised (PA66HS), Polyamide 6.6, high impact modified, heat stabilised (PA66HIRHS)
Flammability UL 94-V2 (Foot Part: UL 94-HB)
Operating Temperature -40 °C to +105 °C, (+145 °C, 500 h)
ELV compliant Yes
ROHS compliant Yes
Manufacturer HellermannTyton
Product Unit Piece
Drawing

HellermannTyton 156-00969 T50RTC40FT6.35-PA66HS/PA66HIRHS-BK Drawing PDFCAD_17-1587-001-CSH.pdfDrawing

Datasheet

HellermannTyton 156-00969 T50RTC40FT6.35-PA66HS/PA66HIRHS-BK Datasheet PDFTDS_156-00969_com.pdfDatasheet
