118-00014 T30ROS

Standard Cable Tie, Outside Serrated, 148mmx3.4mm(LxW), Bundle Max. Φ35 mm, 135N Tensile Strength, PA66V0, -40 °C to +85 °C, White
Manufacturer: HellermannTyton
SKU: 118-00014
MPN: T30ROS-PA66V0-WH
Product Family: Outside Serrated Cable Tie
Category: Standard Cable Tie
Unit Price: $0.2847
Availability: Out of Stock - on backorder and will be dispatched once in stock.
Price list
Quantity Net Price /Piece
2000 + $0.2847
2500 + $0.2768
3500 + $0.2649
4500 + $0.2560
6000 + $0.2459
7500 + $0.2380
10000 + $0.2278
This product has a minimum quantity of 2000
Total Price: $0.2847
Request a free, non-obligation quote today
Create your individual quote quickly and easily
Full Description

OS-Series cable ties are used in many areas where thin-walled or soft insulation wires and cable are being installed, for instance automotive and aircraft industry. OS ties manufactured from PA66V0 material are suitable for applications where safety regulations require reduction of smoke and dangerous gases.

Features

  • Outside serrated cable tie with smooth surface to the bundle
  • Tie follows the contours of the cable bundle perfectly
  • Takes up less space due to curved head design
  • Easy insertion combined with high tensile strength
  • PA46 material for higher temperatures up to +195 °C (500 h)
  • PA66V0 cable ties fulfill Limited Fire Hazard requirements
  • Easy application either manually or with a processing tool
Products specifications
Attribute name Attribute value
Country of Origin GB
Product Family Outside Serrated Cable Tie
Global Part Number T30ROS-PA66V0-WH
Product Base Type T30ROS
Material Abbreviation PA66V0
Color White
Lead Time 16 Weeks
Tie Closure Plastic Pawl
Variant Outside Serrated
Cable Tie Length (Metric) 148 mm
Cable Tie Length (Imperial) 5.8 inch
Cable Tie Width (Metric) 3.4 mm
Cable Tie Width (Imperial) 0.13 inch
Tie Strap Thickness 1.2 mm
Max. Bundle Diameter Φ35 mm
Min. Tensile Strength (Metric) 135N
Min. Tensile Strength (Imperial) 30 Lbs (13.8 Kgf)
Material Polyamide 6.6 V0 (PA66V0)
Flammability UL 94-V0
EN 45545-2 Classification R22 HL2, R23 HL3
Operating Temperature -40 °C to +85 °C, (+105 °C, 500 h)
Specifications EN45545-2
ELV compliant Yes
ROHS compliant Yes
Halogen-free Yes
Manufacturer HellermannTyton
Product Unit Piece
Drawing

HellermannTyton 118-00014 T30ROS-PA66V0-WH Drawing PDFCAD_141557.pdfDrawing

Datasheet

HellermannTyton 118-00014 T30ROS-PA66V0-WH Datasheet PDFTDS_118-00014_com.pdfDatasheet
